High-Performance
HSS-E/PM End Mills • Roughing
Series 620V • WavCut™ II • Lists 620V 621V 622V 623V 625V
|
|
|
|
- Center cutting.
- WavCut.
- 4-Flute End Mills have a helix = 35°.
- 6-Flute End Mills have a helix = 28°.
- Standard items listed.
Additional
styles and coatings made to order.
|
|
|
 |
|
| D1
|
D
|
length
of cut Ap1 max |
length
L |
Rε |
BCH |
Z
U |
UNCOATED
- WW |
TiAlN
- LW |
| 3/4 |
3/4 |
1 5/8 |
3 7/8 |
- |
.039 |
4 |
620V19077 |
TF620V19077 |
| 3/4 |
3/4 |
2 1/4 |
4 1/2 |
- |
.039 |
4 |
623V19077 |
TF623V19077 |
| 3/4 |
3/4 |
3 |
5 1/4 |
- |
.039 |
4 |
621V19077 |
TF621V19077 |
| 3/4 |
3/4 |
4 |
6 1/4 |
- |
.039 |
4 |
622V19077 |
TF622V19077 |
| 1 |
1 |
2 |
4 1/2 |
- |
.039 |
4 |
620V25078 |
TF620V25078 |
| 1 |
1 |
2 |
4 1/2 |
.060 |
- |
6 |
620V25288 |
TF620V25288 |
| 1 |
1 |
3 |
5 1/2 |
- |
.039 |
4 |
623V25078 |
TF623V25078 |
| 1 |
1 |
3 |
5 1/2 |
.060 |
- |
6 |
623V25288 |
— |
| 1 |
1 |
4 |
6 1/2 |
- |
.039 |
4 |
621V25078 |
TF621V25078 |
| 1 |
1 |
4 |
6 1/2 |
.060 |
- |
6 |
621V25288 |
— |
| 1 |
1 |
6 |
8 1/2 |
- |
.039 |
4 |
622V25078 |
TF622V25078 |
| 1 1/4 |
1 1/4 |
2 |
4 1/2 |
- |
.039 |
4 |
620V32079 |
TF620V32079 |
| 1 1/4 |
1 1/4 |
2 |
4 1/2 |
.060 |
- |
6 |
620V32289 |
TF620V32289 |
| 1 1/4 |
1 1/4 |
3 |
5 1/2 |
- |
.039 |
4 |
623V32079 |
TF623V32079 |
| 1 1/4 |
1 1/4 |
3 |
5 1/2 |
.060 |
- |
6 |
623V32289 |
TF623V32289 |
| 1 1/4 |
1 1/4 |
4 |
6 1/2 |
- |
.039 |
4 |
621V32079 |
TF621V32079 |
| 1 1/4 |
1 1/4 |
4 |
6 1/2 |
.060 |
- |
6 |
621V32289 |
TF621V32289 |
| 1 1/4 |
1 1/4 |
6 |
8 1/2 |
.060 |
- |
6 |
622V32289 |
TF622V32289 |
| 1 1/2 |
1 1/4 |
2 |
4 1/2 |
- |
.039 |
4 |
620V38079 |
TF620V38079 |
| 1 1/2 |
1 1/4 |
2 |
4 1/2 |
.060 |
- |
6 |
620V38289 |
— |
| 1 1/2 |
1 1/4 |
3 |
5 1/2 |
- |
.039 |
4 |
623V38079 |
TF623V38079 |
| 1 1/2 |
1 1/4 |
3 |
5 1/2 |
.060 |
- |
6 |
623V38289 |
— |
| 1 1/2 |
1 1/4 |
4 |
6 1/2 |
- |
.039 |
4 |
621V38079 |
TF621V38079 |
| 1 1/2 |
1 1/4 |
4 |
6 1/2 |
.060 |
- |
6 |
621V38289 |
— |
| 1 1/2 |
1 1/4 |
6 |
8 1/2 |
.060 |
- |
6 |
622V38289 |
— |
| 2 |
2 |
2 |
5 3/4 |
.060 |
- |
6 |
625V51222 |
— |
| 2 |
2 |
3 |
6 3/4 |
- |
.039 |
4 |
625V51731 |
TF625V51731 |
| 2 |
2 |
3 |
6 3/4 |
- |
.039 |
8 |
625V51733 |
TF625V51733 |
| 2 |
2 |
3 |
6 3/4 |
.060 |
- |
6 |
625V51232 |
— |
| 2 |
2 |
4 |
7 3/4 |
- |
.039 |
4 |
625V51741 |
TF625V51741 |
| 2 |
2 |
4 |
7 3/4 |
- |
.039 |
8 |
625V51743 |
TF625V51743 |
| 2 |
2 |
4 |
7 3/4 |
.060 |
- |
6 |
625V51242 |
TF625V51242 |
| 2 |
2 |
6 |
9 3/4 |
- |
.039 |
4 |
625V51761 |
TF625V51761 |
| 2 |
2 |
6 |
9 3/4 |
- |
.039 |
8 |
625V51763 |
TF625V51763 |
| 2 |
2 |
6 |
9 3/4 |
.060 |
- |
6 |
625V51262 |
TF625V51262 |
| 2 |
2 |
8 |
11 3/4 |
.060 |
- |
6 |
625V51282 |
— |
|
