Boring Bars
Clampling System S A-PWLN 95° |
|
|
|
  |
Steel shank with through coolant
See pages B43–B45, B59, and B87 for inserts. |
|
|
| Order
# |
catalog
number |
D |
D min |
F |
L1 |
L2 |
CS |
γF° |
γP° |
gage insert |
shim |
shim pin |
pin punch |
lever |
lever screw |
Torx plus |
| Right Hand |
| 3883459 |
A16RPWLNR06 |
16 |
27 |
11,0 |
200 |
32 |
1/8-27 NPT |
-12.0 |
-5.0 |
WN..060408 |
|
|
|
511.030 |
514.112 |
8 IP |
| 3883455 |
A20SPWLNR06 |
20 |
25 |
13,0 |
250 |
32 |
1/8-27 NPT |
-14.0 |
-5.0 |
WN..060408 |
|
|
|
511.030 |
514.112 |
8 IP |
| 3883458 |
A25RPWLNR08 |
25 |
32 |
17,0 |
200 |
40 |
1/4-18 NPT |
-12.0 |
-5.0 |
WN..080408 |
512.135 |
513.023 |
515.018 |
511.023 |
514.123 |
15 IP |
| 3883454 |
A32SPWLNR08 |
32 |
40 |
22,0 |
250 |
50 |
1/4-18 NPT |
-10.0 |
-5.0 |
WN..080408 |
512.135 |
513.023 |
515.018 |
511.023 |
514.123 |
15 IP |
| Left Hand |
| 3883461 |
A16RPWLNL06 |
16 |
27 |
11,0 |
200 |
32 |
1/8-27 NPT |
-12.0 |
-5.0 |
WN..060408 |
|
|
|
511.030 |
514.112 |
8 IP |
| 3883457 |
A20SPWLNL06 |
20 |
25 |
13,0 |
250 |
32 |
1/8-27 NPT |
-14.0 |
-5.0 |
WN..060408 |
|
|
|
511.030 |
514.112 |
8 IP |
| 3883460 |
A25RPWLNL08 |
25 |
32 |
17,0 |
200 |
40 |
1/4-18 NPT |
-12.0 |
-5.0 |
WN..080408 |
512.135 |
513.023 |
515.018 |
511.023 |
514.123 |
15 IP |
| 3883456 |
A32SPWLNL08 |
32 |
40 |
22,0 |
250 |
50 |
1/4-18 NPT |
-10.0 |
-5.0 |
WN..080408 |
512.135 |
513.023 |
515.018 |
511.023 |
514.123 |
15 IP |
|
|
