Miniature Tool Holders
Clampling System S LR Series 50° Boring Bar |
|
|
|
  |
Steel shank without through coolant
See pages B14–B16, B46,
and B70–B71 for inserts. |
|
|
| Order
# |
ISO catalog
number |
B |
F |
H |
H1 |
L1 |
gage insert |
insert screw |
Torx |
Nm |
| Left Hand |
| 2024091 |
S08ASCMCN065 |
8,00 |
0,00 |
7,00 |
6,00 |
32,00 |
CC..0602.. |
12148068700 |
T8 |
1,0 |
| 2012035 |
S10BSCMCN06 |
10,00 |
0,00 |
9,00 |
7,00 |
40,00 |
CC..0602.. |
12148068700 |
T8 |
1,0 |
| 2031113 |
S12DSCMCN06 |
12,00 |
0,00 |
11,00 |
8,00 |
60,00 |
CC..0602.. |
12148068700 |
T8 |
1,0 |
| 2031119 |
S16FSCMCN09 |
16,00 |
0,00 |
15,00 |
10,00 |
80,00 |
CC..0903.. |
12148095100 |
T15 |
3,0 |
| 2030994 |
12157301800 |
16,00 |
0,00 |
15,00 |
10,00 |
80,00 |
CC..09T3.. |
12148095100 |
T15 |
3,0 |
|
|
