CLICK TOOL NUMBERS TO ORDER
| 770 PGT/ER COLLETS |
| Part Number |
A |
B |
D=16mm
L=27.5mm |
D=20mm
L=31.5mm |
D=25mm
L=34mm |
D=32mm
L=40mm |
D=40mm
L=46mm |
Inches |
ANSI Metric |
| 100PGT-#8 |
0.168 |
0.131 |
ERT16-#8 |
ERT20-#8 |
ERT25-#8 |
ERT32-#8 |
- |
#8 |
M4 |
| 100PGT-#10 |
0.194 |
0.152 |
ERT16-#10 |
ERT20-#10 |
ERT25-#10 |
ERT32-#10 |
- |
#10 |
M4.5,M5 |
| 100PGT-#12 |
0.220 |
0.165 |
ERT16-#12 |
ERT20-#12 |
ERT25-#12 |
ERT32-#12 |
- |
#12 |
- |
| 100PGT-012N |
0.437 |
0.328 |
- |
- |
- |
ERT32-012N |
ERT40-012N |
1/8 NPT |
- |
| 100PGT-025 |
0.255 |
0.191 |
ERT16-025 |
ERT20-025 |
ERT25-025 |
ERT32-025 |
ERT40-025 |
1/4 |
M6,M6.5 |
| 100PGT-025N |
0.562 |
0.421 |
- |
- |
- |
ERT32-025N |
ERT40-025N |
1/4 NPT |
- |
| 100PGT-031 |
0.318 |
0.238 |
- |
ERT20-031 |
ERT25-031 |
ERT32-031 |
ERT40-031 |
5/16 |
M7,M8 |
| 100PGT-037 |
0.381 |
0.286 |
- |
ERT20-037 |
ERT25-037 |
ERT32-037 |
ERT40-037 |
3/8 |
M10 |
| 100PGT-037N |
0.700 |
0.531 |
- |
- |
- |
- |
ERT40-037N |
3/8 NPT |
- |
| 100PGT-043 |
0.323 |
0.242 |
- |
ERT20-043 |
ERT25-043 |
ERT32-043 |
ERT40-043 |
7/16 |
- |
| 100PGT-050 |
0.367 |
0.275 |
- |
ERT20-050 |
ERT25-050 |
ERT32-050 |
ERT40-050 |
1/2 |
M12,M12.5 |
| 100PGT-050N |
0.687 |
0.515 |
- |
- |
- |
- |
ERT40-050N |
1/2 NPT |
- |
| 100PGT-056 |
0.429 |
0.322 |
- |
- |
ERT25-056 |
ERT32-056 |
ERT40-056 |
9/16 |
M14 |
| 100PGT-062 |
0.480 |
0.360 |
- |
- |
ERT25-062 |
ERT32-062 |
ERT40-062 |
5/8 |
M16 |
| 100PGT-068 |
0.542 |
0.406 |
- |
- |
- |
ERT32-068 |
ERT40-068 |
11/16 |
M18 |
| 100PGT-075 |
0.590 |
0.442 |
- |
- |
- |
ERT32-075 |
ERT40-075 |
3/4 |
- |
| 100PGT-081 |
0.652 |
0.489 |
- |
- |
- |
ERT32-081 |
ERT40-081 |
13/16 |
M20 |
| 100PGT-087 |
0.697 |
0.523 |
- |
- |
- |
- |
ERT40-087 |
7/8 |
M22 |
| 100PGT-093 |
0.760 |
0.570 |
- |
- |
- |
- |
ERT40-093 |
15/16 |
M24 |
| 100PGT-100 |
0.800 |
0.600 |
- |
- |
- |
- |
ERT40-100 |
1 |
M25 |
For ER11 collets, see Toolholding. For #2 - #6 taps use ERXX-0157, square drive not required. |
|
